Antenna Products

The advantages of our Antenna Products include their exceptional performance in challenging environments, offering reliable connectivity with low latency and high data throughput. Their compact, lightweight designs make them suitable for space-constrained applications, while their durability ensures long-lasting use, even in harsh weather conditions. The antennas also feature easy integration with existing communication systems, making them ideal for upgrading or expanding network infrastructure. With customizable options available to suit specific needs, our antenna products deliver cost-effective solutions for a wide range of applications, providing businesses and industries with a dependable and efficient means of communication.

DESCRIPTION

Product Examples

Measurement and control antenna

Project	Indicator requirements	Note
Frequency range	7.2-8.4GHz
±70° gain	>1.0dB
Standing Wave	＜2dB	Receive greater than -1dBi
Polarization	LHCP&RHCP	Design available on request
Number of Input Ports	1
Weight	<50g
Temperature Range	-90℃~+90℃

Digital transmission antenna

Project	Indicator requirements	Note
Frequency range	8025-8400MHz
Remote control frequency suppression regime	>20dB	7235-7250MHz
Normal Gain	>15.0dB
±5° Gain	>14.0dB
Polarization	Bilinear polarization synthesis LHCP+RHCP
Number of Input Ports	2	2 SMP inputs for a single antenna
Weight	<70g
Temperature Range	-90℃~+90℃

Microstrip Digital Transmission Antenna

Project	Indicator requirements
Frequency Range	8025-8030/8050-8055MHz
Gain	≥1dBi（±65°）
Standing Wave	＜1.5
Polarization	RHCP&LHCP
Circularly Polarized Axial Ratio (CPA)	AR≤8.0dB（θ≤±65°）
Number of Input Ports	1
Weight	<75 g
Temperature Range	-90℃~+90℃

Dual Polarized Horn Digital Transmission Antenna

Project	Indicator requirements
Frequency Range	8100-8400MHz
Gain	Better than 16dBi，0≤θ≤10º； Better than 14dBi （0≤θ≤10º，0≤ϕ≤360º）
Standing Wave	<2
Polarization	LHCP+RHCP
Circularly Polarized Axial Ratio (CPA)	<5.2dB（0≤θ≤30º，0≤ϕ≤360º）
Number of Input Ports	2
Weight	<210g
Temperature Range	-90℃~+90℃

Our Antenna Products range includes high-performance antennas designed for a variety of communication, navigation, and wireless applications. These antennas are built with advanced materials and technology to ensure optimal signal reception, transmission, and durability in demanding environments. Available in a range of designs, including omnidirectional, directional, and phased array antennas, our products are tailored to meet the needs of sectors such as telecommunications, aerospace, defense, IoT, and automotive. The antennas are engineered for wide frequency coverage, supporting both low and high-frequency bands for reliable, long-range communication. Designed for ease of installation and integration, they provide superior efficiency, minimal interference, and robust performance in both urban and remote settings. The product line includes options for outdoor, indoor, and mobile applications, ensuring compatibility with a wide range of devices and systems.
